| Model | DP-40C | DP-90C | DP-120C | DP-180C | DP-200C | |
|---|---|---|---|---|---|---|
| Frequency | Hz | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Max. Air Flow | L/min | 46/50 | 56/66 | 79/91 | 125/150 | 145/170 |
| Con. Pressure | Kgf/㎝2 | 3.5 | 3.5 | 1.75 | 3.5 | 3.5 |
| psi | 50 | 50 | 25 | 50 | 50 | |
| Max. Pressure | Kgf/㎝2 | 7 | 7 | 3.5 | 7 | 7 |
| psi | 100 | 100 | 50 | 100 | 100 | |
| Motor Pole | Pole | 4 | 4 | 4 | 4 | 4 |
| Motor Phase | φ | 1 | 1 | 1 | 1 | 1 |
| Motor Voltage | Volt | 100V~115V | ||||
| 200V~240V | ||||||
| Motor Output | Watt | 300W | 350W | 400W | 750W | 750W |
| Noise Level | Db | 59/62 | 61/63 | 61/63 | 67/68 | 67/68 |
| Ambient Temp | ℃ | 7~40℃ | 7~40℃ | 7~40℃ | 7~40℃ | 7~40℃ |
| Net Weight | Kg | 6.8 | 8.4 | 8.4 | 11.5 | 11.5 |
